Imaginary Picture of Kepler-783 c

Display orbital revolution of Kepler-783 c around the hoststar Kepler-783
/
Exoplanet Name : Kepler-783 c
Alternate Name : "2MASS J19241510+4729052 c, K01165.01, KIC 10337517 c, KOI-1165 c, KOI-1165.01, WISE J192415.08+472905.3 c"
Status : Confirmed
Radius (Rjup / Re): 0.2080 (Rjup) 2.3315 (Rearth)
Mass (Mjup / Me): 0.0182 (Mjup) 5.7971 (Mearth)
Semi Major Axis / Orbital Distance Calculated 0.0000 (AU) 0.0703 (AU Est.)
Eccentricity : 0.0000
Orbital Period(Yrs) 0.0193
Orbital Period(Observed/Estimated) 7.05 (Days Obs.) 0.00 (Days Est.)
Surface Gravity (G Earth) 1.0665
Star Radiation at Atmospheric Boundary: 182814.6 (W/m2)
Measured Temperature (K) 0.0 (K)
Blackbody T 0.1(K) 922.9 (K)
Blackbody T 0.3(K) 866.7 (K)
Blackbody T 0.7(K) 701.2 (K)
Tidally Locked Blackbody T 0.1(K) 1097.5 (K)
Tidally Locked Blackbody T 0.3(K) 1030.7 (K)
Size Class: sub-Neptune-size
Mass Class:
Detection Type : Primary Transit
Mass Detection :
Radius Detection :
Habitability by Solar Eq. Astronomical Unit: Not habitable
Habitability by Kopparapu: Not habitable
Star Name : Kepler-783
Alternate Name : "2MASS J19241510+4729052, KIC 10337517, KOI-1165, WISE J192415.08+472905.3"
Star Distance(LY) : 1774.3
Stellar Radius(Rsun) : 0.9 (Rsun Measured)
Stellar Mass(Msun) : 0.9 (Msun Measured) 0.9 (Msun Estimated)
Star Age : 3.9 (GY)
Temperature : 5521 (K)
Spectral type : G7
UV portion[%]: 7.0
Visible portion[%]: 43.4
IR portion[%]: 49.6
Metalicity : 0.0
Absolute Magnitude: 4.0
Apparent Magnitude: 12.7
Right Ascension(RA) 291.0629
Declination (DEC) 47.4848
Hubble Space Telescope Guide Star Catalog (GSC) ID
Discovered by
Discovery Paper - Authors
Discovery Paper - Title
Discovery Paper - Journal
Discovery Paper - URL
SIMBAD LINK http://simbad.u-strasbg.fr/simbad/sim-basic?Ident=Kepler-783+&submit=SIMBAD+search
Open Exoplanet Database Link
Kepler-783 c
Kepler-783 c

  • Kepler-783 c is an exoplanet orbiting the star Kepler-783, located about 1774.3 light-years (544.0 pc) away from Solar System. Its discovery was publicly announced on 2020.
  • The host star Kepler-783 has apparent magnitude of 12.7, with absolute magnitude of 4.0.
  • It is 0.9 times more massive and 0.9 times bigger compared with our Sun. The surface temperature is 5521 with its spectral types of G7
  • In this planetary system, the extrasolar planet Kepler-783 c orbits around the star Kepler-783 every 7.1 days with its orbital distance of 0.07 AU ( 10511091.8 km)
  • (Projected orbit of Kepler-783 c around its host star Kepler-783)


  • The Star Kepler-783 's habitable zone is located at the following distance
  • Inner Boundary (the orbital distance at Venus's Equivalent Radiation ) : 0.588 AU ( 87919176.9 km)
  • Earth Boundary (the orbital distance at Earth's Equivalent Radiation) : 0.812 AU ( 121527278.5 km)
  • Outer Boundary (the orbital distance at Mars's Equivalent Radiation) : 1.238 AU ( 185180678.4 km)
  • Snow Line (the orbital distance at Snow Line Equivalent Radiation) : 1.822 AU ( 272501480.6 km)
  • Radiation at Planetary Boundary of Kepler-783 c : 182814.64 W/m2

    (Habitable zone calculated based on SEAU(Solar Equivalent Astronomical Unit) around the star Kepler-783)



  • Kopparapu Recent Venus for Star Kepler-783 distance : 0.618 AU
  • Kopparapu Runaway Greenhouse for Earth-sized planet for Star Kepler-783 distance : 0.783 AU
  • Kopparapu Runaway Greenhouse for Super-Earth-sized planet for Star Kepler-783 distance : 0.756 AU
  • Kopparapu Runaway Greenhouse for Mars-sized planet for Star Kepler-783 distance : 0.829 AU
  • Kopparapu Outer Boundary for Maximum Greenhouse for Star Kepler-783 distance : 1.393 AU
  • Kopparapu Outer Boundary for Early Mars for Star Kepler-783 distance : 1.469 AU

    (Habitable zone calculated based on Kopparapu et al.(2013) around the star Kepler-783)



  • Original Kopparapu Recent Venus for Star Kepler-783 distance : 0.616 AU
  • Original Kopparapu Runaway Greenhouse for Star Kepler-783 distance : 0.805 AU
  • Original Kopparapu Moist Greenhouse for Star Kepler-783 distance : 0.815 AU
  • Original Kopparapu Outer Boundary for Maximum Greenhouse for Star Kepler-783 distance : 1.417 AU
  • Original Kopparapu Outer Boundary for Early Mars for Star Kepler-783 distance : 1.474 AU

    (Habitable zone calculated based on Kopparapu et al.(Original) around the star Kepler-783)



    (Position in Stellar Map of star Kepler-783 and its Exoplanet Kepler-783 c)



    (Zoomed position in Stellar Map of star Kepler-783 and its Exoplanet Kepler-783 c (zoom level 3))

    (Synthetic Spectrum of star Kepler-783*)
    *Yamashiki YA et al. 2019 ApJ 881 114
    MUSCLES Paper I - France et al. 2016 ApJ 820 89
    MUSCLES Paper II- Youngblood et al. 2016 ApJ 824 101
    MUSCLES Paper III- Loyd et al. 2016 ApJ 824 102
